European Wall Mount Power Adapter

European Wall Mount Power Adapter

  • European Wall Mount Power Adapter
  • European Wall Mount Power Adapter
  • European Wall Mount Power Adapter
European Wall Mount Power Adapter
পণ্যের বিবরণ:
Place of Origin: China
পরিচিতিমুলক নাম: STARWELL
সাক্ষ্যদান: UL,CE,ROHS, FCC,GS,SAA,C-TICK
Model Number: SMS-01120100-S04US
প্রদান:
Minimum Order Quantity: 100pcs
মূল্য: negotiation
Packaging Details: Carton box
Delivery Time: 10-15 days
Payment Terms: Ex works
Supply Ability: 1, 000, 000PCS/week
যোগাযোগ
বিস্তারিত পণ্যের বর্ণনা
লক্ষণীয় করা:

external power adapter

,

portable power adapter





European 12V DC 1A Network Wall Mount Power Adapter 12W EN61000 3-3





Feartures:





> input voltage range: 100~240VAC

> output: 12V 1A

> Effiency: 85% minimum

> Ripple and Noise: 80mV maximum

> Color: Black or white

> Dc cable length: 1.5 meters

> DC jack: 5.5*2.1*10mm

> Weight: 90g

> AC Plug:  US , EU , AU ,UK plug avaliable

> Safety protection: over load, over voltage, short ciruict, open load protection.




Specifications:







Input Rated Voltage :

100Vac~240Vac

Input Frequency Range:

47Hz~63Hz

Input Inrush Current :

0.3A max

Efficiency  :

85%(MIN)at Rated Voltage

Output:

12V 1000mA

Output power :

12W

Ripple and Noise :

<80Mv at full road with 20MHz bandwidth

Turn On Delay Time:

<3S  (AC:110V and full load)

Safety protection :

over voltage and current protection.

Leakage Current:

<5mA

USB connector:

5.5*2.1*10mm

Operating Temperature:

0°C----+60°C

Storage Temperature:

-20°C----+85°C

Certificate:

CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK

Safety Standard :

EN60950-1 UL60950-1  ESD (EN61000 3-3)
CAS (60950 ITE/TE)  FCC Part 15 subpart B Class B
AN/NZS CISPR 22:2006

Application:

For battery charger, mobile phone, cell phone, iphone etc…



MODEL LIST:





12W SERIES

Model

Input Voltage

Power

Output Voltage

Output Current

Plug type

SMS-01090100-S04ZZ

100-240VAC

9W

9V

1A

EU,US,UK,AU

SMS-01100100-S04ZZ

100-240VAC

10W

10V

1A

EU,US,UK,AU

SMS-01050200-S04ZZ

100-240VAC

10W

5V

2A

EU,US,UK,AU

SMS-01060200-S04ZZ

100-240VAC

12W

6V

2A

EU,US,UK,AU

SMS-01120100-S04ZZ

100-240VAC

12W

12V

1A

EU,US,UK,AU

SMS-01240050-S04ZZ

100-240VAC

12W

24V

0.5A

EU,US,UK,AU

SMS-01XXXYYY-S04ZZ

SMS-01XXXYYY-S04ZZ ( XXX=030-240 means the output voltage is 3-24V

YYY=001-500, means the output current is 0.01-5.00A

ZZ= US, AU,EU,BS(means US plug, AU plug, UK plug,)



DRAWING:



European Wall Mount Power Adapter  0





European Wall Mount Power Adapter  1



EMC Standards & Safety Standards / EMC Standards





1.1.    EMC Standards





GB9254

GB17625.1

GB13837

FCC- Part15

EN 55022

EN55024

CISPR 22

EN 61000-4-4

EN 61000-3-2

EN 61000-3-3

EN 61000-4-2

EN 61000-4-3

EN 61000-4-5

EN 61000-4-6

EN 61000-4-8

EN 61000-4-11



1.2.    Safety Standards



Type

Country

Standard

Type

Country

Standard

CCC

China

GB4943

CE

Europe

EN60950-1

CCC

China

GB8898

CB

CB

IEC60950

UL/CUL

USA

UL60950-1

C-TICK

Australia

AS/NZ60950

KC

Korea

KC60950

GS/TUV

German

EN60950





INSTRUCTION:



- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

- The mains plug is used as the disconnect device, the disconnect device shall be readily operable.

- The socket-outlet shall be installed near the equipment and shall be easily accessible.

- No naked flame source, such as lighted candles, should be placed on the apparatus.

- Maximum operating ambient for the equipment is 40℃.

- The apparatus should not be used in a confined space such as a bookcase.

- This appliance is not intended for use by persons (including children) with reduced physical,

sensory, or mental capacities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their Safety.

- Children should be supervised to ensure that they do not play with the appliance.
